TGT 1250 IP55 axial fans with adjustable blades

Cabinet

It is available in short or long version, welded from corrosion-resistant steel sheet with hot-dip galvanized surface, with flanges for circular pipes. In the long version, service door on request.

Running wheel

is made of Al alloy and is statically and dynamically balanced. The impeller blade angle is adjusted by the manufacturer (18º - 34º). Number of blades 3, 6, 9 or 12.

Square wheel

External terminal blocks in CK, LK and LPK versions as standard.

Motor

is asynchronous with short armature. The motors are with class F insulation and operating temperature -20 to +40 °C. IP55 protection. Efficiency class IE3.

Speed control

is possible on selected types by frequency converter - please check current delivery options.

Flow direction

is standard from impeller to motor (B).

Mounting

fan in any position, preferably with the motor axis horizontal. The casing must not transmit mechanical stresses from the pipework. A flexible connection to the pipework must be used.

Air handling accessories

- ACOP flexible coupling
- BRIDA loose flange
- DEF-A, D protective grilles
- PIE mounting brackets
- PER plastic lone louver
- TRK, TRKS metal lone louver
- PAR, PMR plastic louvre dampers
- PRG, TWG plastic rain shutters
- TAD inlet nozzle
- TSK, TSKM pipe check dampers
- TAA, TAAC silencers
- KSE vibration dampers

EL Accessories

- VFKB, VFTM frequency converter
- VFVN frequency converter
- PM 55 control switch
